China 5050 Lens Mini Wallwasher LED strip light Manufacturer and Supplier

5050 Lens Mini Wallwasher LED strip light

Inquire

Product Details

Technical Spec

Download

● Adopts 38° beam angle 5050 lens LED lamp beads, which helps to improve the illumination level.

● Compared with 120° beam angle light strips, it provides more concentrated lighting and longer irradiation distance, helping to achieve higher light utilization efficiency and higher central illumination under the same luminous flux.

● Optimized structural design contributes to better optical efficiency. The product uses flame-retardant and UV-resistant materials.

● Supports multiple versions including RGB, SPI RGB and white light.

● Available in a maximum length of 5m per roll, and can be cut on-site to meet different length requirements

Color rendering is a measure of how accurate colors appear under the light source. Under a low CRI LED strip, colors might appear distorted, washed out, or indistinguishable. High CRI LED products offer light that allows objects to appear the way they would under an ideal light source such as a halogen lamp, or natural daylight. Also look for a light source’s R9 value, which provides further information about how red colors are rendered.

Need help deciding which color temperature to choose? See our tutorial here.

Adjust the sliders below for a visual demonstration of CRI vs CCT in action.

Warmer ← CCT → Cooler

Lower ← CRI → Higher

#ERP #UL #ARCHITECTUR #COMMERCIAl #HOME

This new 5050 Mini Wallwasher strip is an upgraded version of the Wallwasher series. It features a more compact size while maintaining the same functions as the larger wallwasher models. Its advantages are as follows:

Adopts 5050 lens RGB LED chips with a 38° beam angle, which helps improve illumination performance.
Compared with 120° beam angle strips, it provides more concentrated light output and longer irradiation distance, contributing to better light efficiency and central illumination under the same luminous flux.
Optical efficiency is enhanced through optimized structural design. The product uses flame-retardant and UV-resistant materials.
Supports various RGB SPI, DMX and white light output modes.
Available in rolls up to 5m; can also be cut on-site to meet different length requirements.
With IP65/IP67 protection, suitable for both indoor and outdoor applications.

LED wall washer strips help reduce energy consumption compared with traditional wall washing lamps. Long-term large-area use can help save urban power consumption, so many projects are gradually replacing traditional rigid wall washers with flexible LED wall washer strips.

LED wall washer products do not release harmful substances and are environmentally friendly.

LED wall washer strips support rich color options and can be controlled via programs to create diverse wall-washing lighting effects, bringing rich and varied lighting scenes. They are suitable for installation on different types of buildings.

If you need to match this product with other light strips, we can provide professional suggestions. You may also need high-voltage strips, neon flex for exterior decoration; length, power and lumen parameters can be customized according to your requirements.

You can rely on our product quality and on-time delivery. We have our own production workshop of more than 20,000 square meters, with complete production and testing equipment.

Our product range includes SMD series, COB series, CSP series, neon flex, high-voltage strips, dynamic pixel strips and wall-washer strips.

If you need samples for testing or more product information, please contact our sales team.

SKU	Width	Voltage	W/m	Cut	Lm/M	Color	CRI	IP	Control	L70
MF35LA060Q00-D000D6F10106S	12MM	24V	13.5W	100MM	440	RGB	NA	IP65	SPI	35000H
MF35LA060A00-D000J1F10106N	10MM	24V	16W	100MM	500	RGB	NA	IP20	On/Off RGB remote	35000H
MF35LA060A00-D000J1F10106S	10MM	24V	13.5W	100MM	400	RGB	NA	IP20	SPI	35000H
MF35LW060Q80-D040B1F10106N	12MM	24V	15W	100MM	1480	4000K	>80	IP65	PWM	35000H
MF35LW060A00-D040A1F10106N	10MM	24V	15W	100MM	1500	4000K	>80	IP20	PWM	35000H
