●High energy efficiency, power consumption reduced by up to 50%, luminous efficacy over 180LM/W
●Mature product series, suitable for a wide range of application scenarios
●Operating / Storage Temperature: Ta: -30~55°C / 0°C~60°C
●Rated lifespan: 35000 hours, with 3 years product warranty
Color rendering is a measure of how accurate colors appear under the light source. Under a low CRI LED strip, colors might appear distorted, washed out, or indistinguishable. High CRI LED products offer light that allows objects to appear the way they would under an ideal light source such as a halogen lamp, or natural daylight. Also look for a light source’s R9 value, which provides further information about how red colors are rendered.
Need help deciding which color temperature to choose? See our tutorial here.
Adjust the sliders below for a visual demonstration of CRI vs CCT in action.
The SMD Series High Power LED Flex Light adopts single-chip high-power and high-efficiency SMD LEDs.Featuring flexible installation and low-profile design, this light fixture suits both commercial and residential environments, and can be well integrated into modern architectural layouts.It delivers good energy-saving performance, cutting power consumption by up to 50% compared with HID, T8 halogen and fluorescent lighting, with noticeably improved lumen output.
The full SMD LED series adopts standard semi-pitch structure and high light transmittance materials.Optimized 12-point connection design and dual reflow structure bring stable service life, reliable energy efficiency and steady current output.The customized reflector material helps achieve uniform light distribution.
The core features of SMD LEDs include low driving current, long service life and high luminous efficiency, making them compatible with most architectural lighting fixtures.
The SMD series LED strip is a mature product line adaptable to diverse project needs.It adopts premium 2835 SMD LEDs and PCB board for heat dissipation, suitable for cove lighting, architectural accent lighting, channel letter lighting and many other scenarios.It has a rated lifespan of 35000 hours, with pure white light at 6000K and luminous efficacy reaching up to 180LM/W.It provides multiple specification options with steady brightness, low power consumption and reliable durability for different application demands.
Suitable for various indoor commercial and residential lighting projects, the SMD series combines high lumen output and energy-efficient performance.With a wide beam angle and low heat generation, it creates a comfortable lighting environment while maintaining good energy-saving effects.
|
SKU |
Width |
Voltage |
W/m |
Cut |
Lm/M |
Color |
CRI |
IP |
IP Material |
Control |
L70 |
|
MF321V560A90-D027A1A10 |
10MM |
DC24V |
22W |
16.7MM |
1760 |
2700K |
90 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
35000H |
|
MF321V560A90-D030A1A10 |
10MM |
DC24V |
22W |
16.7MM |
1870 |
3000K |
90 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
35000H |
|
MF321V560A90-D040A1A10 |
10MM |
DC24V |
22W |
16.7MM |
1980 |
4000K |
90 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
35000H |
|
MF321V560A90-D050A1A10 |
10MM |
DC24V |
22W |
16.7MM |
2090 |
5000K |
90 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
35000H |
|
MF321V560A90-D060A1A10 |
10MM |
DC24V |
22W |
16.7MM |
2090 |
6000K |
90 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
35000H |
