2110SMD-700LED-21


Product Details

Technical Spec

Download

●HIGH EFFICENCY SAVING UP TO 50% POWER CONSUPTION REACHING >180LM/W

●POPULAR SERIES WITH THE RIGHT FIT FOR YOUR APPLICATION

●Working/Storage Temperature: Ta:-30~55°C / 0°C~60°C.

●Lifespan: 35000H, 3 years warranty

5000K-A 4000K-A

Color rendering is a measure of how accurate colors appear under the light source. Under a low CRI LED strip, colors might appear distorted, washed out, or indistinguishable. High CRI LED products offer light that allows objects to appear the way they would under an ideal light source such as a halogen lamp, or natural daylight. Also look for a light source’s R9 value, which provides further information about how red colors are rendered.

Need help deciding which color temperature to choose? See our tutorial here.

Adjust the sliders below for a visual demonstration of CRI vs CCT in action.

Warmer ← CCT → Cooler

Lower ← CRI → Higher

#ERP #UL #A CLASS

The SMD Series High Power LED Flex Light utilizes a single chip high power, high efficiency SMD LEDs. This flexible, low profile fixture is designed for both Commercial and Residential environments and can be easily integrated into modern architecture. Energy efficient with a 50% power consumption saving when compared to HID T8 Halogen Fluorescent Lighting and a Lumen output that is 15X greater.

The whole series of SMD leds adopt original Semi-Pitch and high transparent materials. Advanced 12 Connections (Made by German Hands) and double reflow structure design leads the advantages of long lifespan, high efficiency and more current output. Especially the special reflector material can guarantee a better light distribution. The main feature of smd leds are low driving current, long lifespan and high lighting efficiency, will be suitable for most building lamps.

The SMD series LED strip is a popular series with the right fit for your application. Using high quality 2835 SMD LEDs and PCB as heat sink, this strip can be used in a wide variety of applications such as cove lighting, architectural accent lighting or channel letters. The life span reaches 35000H and its light color is pure white at 6000K,it is high efficiency, which can be up to 180LM/W. Offer a wide range of choices for your application, such as high brightness, low consumption and excellent durability.

It's the right fit for your application. Ideal for various indoor applications such as commercial lighting and residential lighting solutions, SMD series integrates high lumen output and high efficiency. With its wide beam aiming angle and low heat generation, it provides you with a comfortable environment while maintaining energy-efficient ratio.

SKU

Width

Voltage

Max W/m

Cut

Lm/M

Color

CRI

IP

IP Material

Control

L70

MF321V560A90-D027A1A10

10MM

DC24V

22W

16.7MM

1760

2700K

90

IP20

Nano coating/PU glue/Silicon tube/Semi-tube

On/Off PWM

35000H

MF321V560A90-D030A1A10

10MM

DC24V

22W

16.7MM

1870

3000K

90

IP20

Nano coating/PU glue/Silicon tube/Semi-tube

On/Off PWM

35000H

MF321V560A90-D040A1A10

10MM

DC24V

22W

16.7MM

1980

4000K

90

IP20

Nano coating/PU glue/Silicon tube/Semi-tube

On/Off PWM

35000H

MF321V560A90-D050A1A10

10MM

DC24V

22W

16.7MM

2090

5000K

90

IP20

Nano coating/PU glue/Silicon tube/Semi-tube

On/Off PWM

35000H

MF321V560A90-D060A1A10

10MM

DC24V

22W

16.7MM

2090

6000K

90

IP20

Nano coating/PU glue/Silicon tube/Semi-tube

On/Off PWM

35000H

SMD SERIES
