●Min 1cm cut,good choice with Aluminum profile.
●Fast connector for IP20 and IP65 waterproof,,free soldering connect.
●Conform to “2022 ERP Class B for EU Market”, and conformed to “TITLE 24 JA8-2016 for US Market”
●No voltage drop design for Max length 10m a roll.
●The daily output can reach 30,000 meters.
●Accept custome specification and customized packing.
●Experience working with big brands,can provide OEM and ODM.
Typically, Kelvin temperatures for commercial and residential lighting applications fall somewhere on a scale from 2000K to 6500K,it’s a way to describe the light appearance provided by a light bulb. It is measured in degrees of Kelvin (K) on a scale from 1,000 to 10,000.
Color rendering, expressed as a rating from 0 to 100 on the Color Rendering Index (CRI), describes how a light source makes the color of an object appear to human eyes and how well subtle variations in color shades are revealed. The higher the CRI rating is, the better its color rendering ability.
Adjust the sliders below for a visual demonstration of CRI vs CCT in action.
SMD Series is our new Pro-Grade LED Flex Strip, developed for professional lighting and stage lighting applications.This new generation LED Flex Strip is arranged with high-brightness LEDs in a slim narrow strip layout.The SMD Series Pro-Grade LED Flex Strip delivers high energy efficiency and long rated service life. Its flexible body and cuttable design make it suitable for a wide range of creative lighting projects.The SMD Series can serve as a proper option to meet your project and design requirements.
SMD SERIES PRO LED FLEX is a commercial-grade LED flex strip with low voltage drop, good color rendering performance, long service cycle and wide working temperature range.Adopting constant current drive technology, it fits common application scenarios including theaters, exhibitions, showrooms, galleries, museums and retail shop window lighting.
SMD Series LED Flex provides good color reproduction and even brightness performance.The series achieves high power efficiency and helps users obtain favorable cost-saving benefits.It adopts internationally certified premium aluminum materials to ensure structural stability during installation.
This LED flex strip comes with extended length design, good flexibility and high conversion efficiency.It maintains stable working performance, and is less affected by voltage fluctuation and normal operating temperature changes.It can realize around 20% energy saving compared with conventional mainstream lighting products.The product is equipped with SMD LED light source, with light transmittance over 90%.
Its optimized structural design supports diversified installation methods and relieves concerns about voltage drop and uneven light output.The strip presents stable color consistency and light presentation performance, with a rated service life of 5 years.It complies with RoHS requirements and is covered by a 5-year product warranty.
|
SKU |
Width |
Voltage |
W/m |
Cut |
Lm/M |
Color |
CRI |
IP |
IP Material |
Control |
L70 |
|
MF328V180A8O-D027A1A10 |
10MM |
DC24V |
9.6W |
100MM |
1780 |
2700K |
80 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
50000H |
|
MF328V18OA80-D030A1A10 |
10MM |
DC24V |
9.6W |
100MM |
1850 |
3000K |
80 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
50000H |
|
MF328W18OA80-D040A1A10 |
10MM |
DC24V |
9.6W |
100MM |
1920 |
4000K |
80 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
50000H |
|
MF328W18OA80-DO50A1A10 |
10MM |
DC24V |
9.6W |
100MM |
1940 |
5000K |
80 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
50000H |
|
MF328W180A80-DO60A1A10 |
10MM |
DC24V |
9.6W |
100MM |
1945 |
6000K |
80 |
IP20 |
Nano coating/PU glue/Silicon tube/Semi-tube |
On/Off PWM |
50000H |
